Excel│セルに画像をぴったり合わせる方法

Option Explicit

Public Sub PreviewFitSelectedPictures()
    FitPictures False
End Sub

Public Sub ApplyFitSelectedPictures()
    FitPictures True
End Sub

Private Sub FitPictures(ByVal applyChanges As Boolean)
    Dim selected As ShapeRange, pic As Shape, box As Range
    Dim factor As Double, newWidth As Double, newHeight As Double
    Dim changed As Long
    If TypeName(ActiveSheet) <> "Worksheet" Then Exit Sub
    If ActiveWorkbook.ReadOnly Or ActiveSheet.ProtectDrawingObjects Then
        MsgBox "Use an editable, unprotected COPY of this workbook."
        Exit Sub
    End If
    On Error Resume Next
    Set selected = Selection.ShapeRange
    On Error GoTo Failed
    If selected Is Nothing Then
        MsgBox "Select floating pictures first."
        Exit Sub
    End If
    ' Preflight every selected object before making any changes.
    For Each pic In selected
        If pic.Type <> msoPicture Then
            MsgBox "Select pictures only; groups, charts and buttons are excluded."
            Exit Sub
        End If
        Set box = pic.TopLeftCell.MergeArea
        If box.Width <= 0 Or box.Height <= 0 Or pic.Width <= 0 Or pic.Height <= 0 Then
            MsgBox "A picture or target cell has zero size. No changes made."
            Exit Sub
        End If
    Next pic
    If applyChanges Then
        If MsgBox("Resize selected pictures in this COPY?", vbYesNo) <> vbYes Then Exit Sub
    End If
    For Each pic In selected
        Set box = pic.TopLeftCell.MergeArea
        factor = WorksheetFunction.Min(box.Width / pic.Width, box.Height / pic.Height)
        newWidth = pic.Width * factor
        newHeight = pic.Height * factor
        Debug.Print pic.Name, box.Address, newWidth, newHeight
        If applyChanges Then
            pic.LockAspectRatio = msoTrue
            pic.Width = newWidth
            pic.Left = box.Left + (box.Width - pic.Width) / 2
            pic.Top = box.Top + (box.Height - pic.Height) / 2
            pic.Placement = xlMoveAndSize
            changed = changed + 1
        End If
    Next pic
    MsgBox "Finished. Pictures changed: " & changed & ". Preview is in the Immediate window."
    Exit Sub
Failed:
    MsgBox "Stopped: " & Err.Description & ". Changes so far: " & changed & _
           ". If needed, close this COPY without saving and start from your backup."
End Sub
